Installation
3.1 Overview
Installing the Model ir7000 consists of:
• Unpacking and Inspection
• Mounting
• Gas Connections
• Electrical Connections
• Calibrating the System
3.2 Unpacking and Installation
The analyzer is shipped ready for installation. You should have
received a single carton containing the analyzer and power cord (except
230 VAC versions). If you have ordered an instrument with the optional
O
2
sensor channel, the electrochemical cell will have been installed at the
factory.
Carefully unpack the instrument and inspect it for any damage or
missing components. Signs of damage would include dents, scratches,
broken glass inside the casing etc. Check that you have received the power
cord or battery charger for the portable model. Contact the shipper
immediately to report shipping damage. Contact the factory for missing
parts.
3.3 Mounting the Analyzer
The ir7000 series of analyzers are designed to be used indoors and in
a general-purpose area. The split-architecture models (explosion proof) are
designed to have the analysis unit operate in a hazardous environment
with the control unit remotely located in a general-purpose area.
The instrument must be kept dry and protected from:
• Direct sunlight
• Direct air currents which could affect the temperature of the
sensors
