Appendix IR7000
70
Teledyne Analytical Instruments., - Rev. 3
Dimensions:
Rack mounted: 22.5”L x 17.1”W x 5.25”H
(571mm L x 447mm W x 133mm H)
Portable: 20.0”L x 8.5”W x 5.25”H
(508mm L x 216mm W x 133mm H)
Wall mounted: 24.0”L x 20.0”W x 6.0”D
(609mm L x 508mm W x 152mm D
Weight:
Rack mounted: 38 lbs (17.2 kg)
Portable: 19 lbs (8.6 kg)
Wall mounted: 43 lbs (19.5 kg)
Resolution: 0.1% of f.s. (Trace: 0.1 ppm)
2% of f.s. for oxygen cell
Repeatability: ±0.1% of f.s. (Trace: ±0.5% of f.s.)
Noise: ±0.1% of f.s. (Trace: ±0.5% of f.s.)
Drift: ±0.3% of f.s. determined on max.range
absolute for all other ranges.
Trace: ±1.0% of f.s. determined on
max.range. Absolute for all other ranges.
Response Time (T90): User selectable 15–60 seconds typically
for nominal flow rates
