Fulton Classic ICX or FB-F Vertical Tubeless Boilers (Steam) Oil Fired - Manual (Page 60)

Parts
48-O 4/00
2-12-090 Spring Retainer for burner/pump relay 0.001 0
2-40-403 IDlDO - 120V Relay 2 0.91
2-40-402 IGIDO - 120V Relay 2 0.91
2-40-400 IGlDO-A-120V Relay 2 0.91
2-40-401 ID2DO - 220V Relay 2 0.91
4-45-050 Set of three (3) Coils for ID or IG Type Relay 1 0.45
4-45-051 Set of three (3) Coils ID2D0 - 220V 1 0.45
2-40-131 General Purpose Relay (Ice Cube) - AB 0.8 0.36
2-40-096 Base for Ice Cube Relay 0.1 0.05
2-45-091 On/Off Switch 0.05 0.02
2-45-092 Manual Reset Switch 0.05 0.02
2-45-090 Night Switch for two (2) Pressuretrols 0.05 0.02
2-45-022 Combination Switch - 3 Position Selector Switch - AB- NEMA 4 0.7 0.32
2-40-657 Alarm Horn - 120V 1 0.45
2-45-412 AB Green Panel Light 120V - NEMA 4 0.02 0.01
2-45-413 AB Amber Panel Light 120V - NEMA 4 0.02 0.01
2-45-411 AB Red Panel Light 120V - NEMA 4 0.02 0.01
2-45-410 AB White Panel Light 120V - NEMA 4 0.02 0.01
2-40-567 Motor Contactor - AB - 100 - A09ND3- 120V - 4-60 HP 0.8 0.36
2-40-568 Motor Contactor - AB - 100 - A09NA3- 220V - 4-60 HP 0.8 0.36
2-40-642 3 Phase Motor Contactor - AB- 100 - A12ND3 - 120V- 80-100 HP 0.8 0.36
2-40-641 3 Phase Motor Contactor - AB- 100 - A12NA3 - 220V- 80-100 HP 0.8 0.36
2-40-565 Overload - 1.0-2.9 amps 0.45 0.2
2-40-648 Overload - 1.5-1.6 amps 0.45 0.2
2-40-573 Overload - 3-12 amps 0.45 0.2
2-40-566 Overload - .4-1.6 amps 0.45 0.2
2-40-651 Overload - .6-25 amps 0.45 0.2
2-40-200 Motor Starter Relay -120V - 20 AMP 0.6 0.27
2-40-202 Motor Starter Relay - 120V - 30 AMP 0.5 0.23
Approx. Approx.
Part No. Description Net Weight Net Weight
(lbs.) (kgs.)
