Parts – Fulton Classic ICX or FB-F Vertical Tubeless Boilers (Steam) Oil Fired User Manual
Page 57
Parts
45-O 4/00
Burner Fans:
Size HP
Applicable
Fuel
Hz.
2-30-407
5-1/2 x 1 1/2 x 5/8
4
#2 Oil
60
1.25
0.57
2-30-410
6-1/4 x 1-1/2 x 5/8
6
#2 Oil
50/60
1.6
0.73
2-30-412
7 x 1-1/2 x 5/8
10
#2 Oil or Comb.
60
2
0.91
2-30-413
7 x 2 x 5/8
10
#2 Oil or Comb.
50
2.2
1.00
2-30-414
7-11/16 X 1-1/2 x 5/8
15
#2 Oil or Comb.
60
2.3
1.05
2-30-417
8-3/8 x 1-1/2 x 5/8
15-20
#2 Oil or Comb.
50
2.6
1.18
2-30-418
8-3/8 x 2 x 5/8 -
30
#2 Oil or Comb.
60
3.15
1.43
2-30-431
9-15/16 X 1-1/2 x 5/8
30
#2 Oil or Comb.
50
3.75
1.70
2-30-415
7-11/16 x 2 x 5/8
20
#2 Oil or Comb.
60
2.5
1.14
2-30-559
9-15/16 x 3 x LO75
40-60
#2 Oil or Comb.
50
4
1.82
2-30-565
9-3/16 x 2-1/2 x 1
40
#2 Oil or Comb.
60
3.5
1.59
2-30-825
9-15/16 x 2-1/2 x 1
60
#2 Oil or Comb
60
4
1.82
2-30-559
9-15/16 x 3 x 1
60
#2 Oil or Comb
60
4
1.82
Burner Assembly - Oil
4-45-010
Ignition Cable with Bakelite Terminal
0.5
0.23
2-40-086
Ignition Transformer- Oil 120/60/1
9.3
4.23
2-40-087
Ignition Transformer - Oil 240/60/1
9.3
4.23
2-40-088
IgnitionTransformer- Oil 120/50/1
10.6
4.82
2-40-089
Ignition Transformer - Oil 240/50/1
10.6
4.82
5-30-025
Air Deflector - Oil - 4-6 HP
11
5
5-30-020
Air Deflector - Oil - 10-15 HP
18
8.18
7-30-722
Air Deflector - Oil - 20-30 HP
24
10.91
7-30-724
Air Deflector - Oil - 40-60 HP
24
10.91
5-20-021
Ignition Electrode Holder- 4-60 HP
1
0.45
2-20-021
11" Ignition Electrode
0.2
0.09
5-10-321
10" x 4-1/2" Stainless Steel Ring - 6-15 HP - Oil
12
5.45
5-10-322
15" x 6" Stainless Steel Ring - 20 & 30 HP - Oil
18
8.18
5-10-323
24" x 6" Stainless Steel Ring - 40 & 60 HP - Oil
35
15.91
2-30-325
Oil Pressure Gauge
0.5
0.23
2-30-128
NYC Oil Regulator
2.2
1
2-30-132
Strainer for Pump
0.1
0.05
2-30-133
Seal for Oil Pump
0.1
0.05
2-30-134
Oil Pump 4-30 HP
8
3.64
2-30-135
Oil Pump 40-100 HP
8.4
3.82
2-20-080
Oil Pump Hub 4-60 HP
1
0.4
5-20-065
UK Mounting Air Gate - 4-15 HP
5
2.27
5-20-066
Damper for UK MountingPlate - 4-15 HP
1
0.4
5-20-066
UK Mounting Air Gate - 20-60 HP
5
2.27
5-20-069
Damper for UK Mounting Plate20-60 HP
1
0.4
211-070
Air Backer Plate 4-10 HP
0.5
0.2
211-069
Air Backer Plate 15 HP
0.5
0.2
211-071
Air Backer Plate 20-30 HP
0.5
0.2
211-072
Air Backer Plate 40-60 HP
0.5
0.2
Approx.
Approx.
Part No.
Description
Net Weight Net Weight
(lbs.)
(kgs.)
