INSTALLATION
FTHC-IOM-2012-1001
SECTION 2
2-4
TABLE 1 - SPECIFICATIONS - COIL DESIGN THERMAL FLUID HEATER
Model FTHC
0240
0400
0600
0800
1000
1200
1600
2000
Heat Output
1000 BTU/HR
1000 KCAL/HR
2400
600
4000
1000
6000
1500
8000
2000
10,000
2500
12,000
3000
16,000
4,032
20,000
5,040
Thermal Fluid Content
GAL
LITERS
75
284
115
435
190
719
264
998
325
1230
508
1921
480
1817
1150
4353
Recommended Flow Rate
GPM
M3/HR
150
35
300
69
400
91
600
137
850
193
1000
227
1200
273
1500
341
Typical Circulating Pump Motor
HP
KW
15
11.2
25
18.7
30
22.5
50
37.3
60
45
75
56.3
100
74.5
125
93.2
Typical Burner Motor*
HP
KW
2
1.5
5
3.7
7.5
5.6
10
7.5
15
11.2
15
11.2
30
22.4
30
22.4
Fuel Consumption @ Full Output No.2 Oil
GPH
LITER/HR
23
88
39
148
58
220
77
292
96
364
115
436
143
542
179
678
Natural Gas
FT3/HR
M3/HR
3200
91
5340
152
8000
227
10,700
304
13,340
378
16,000
454
20,000
566
25,000
708
* Standard burner, single fuel applica ons.
Notes: Voltage 3 Phase for Burner and Pump - Each unit has an incorporated stepdown transformer. Fuel up to No. 6 Oil Available for Large Units. Effi
ciency up to 75% Minimum Based
on High Hea ng Value of the Fuel (No. 2 Oil @ 140,000 BTU/GHHV; Natural Gas @ 1000 BTU/ 3HHV. Modula on 3 to 1 Turn Down Ra o. Circula ng pump motor sizes based on standard
pressure (55 PSIG) and viscosity 1 cs, specifi c gravity 0.7, with 25-37 PSID available head for installa on.
TABLE 2 - DIMENSIONS-COIL DESIGN THERMAL FLUID HEATER (SEE FIGURE 2)
Model FTHC
0240
0400
0600
0800
1000
1200
1600
2000
Heater Inlet/ Outlet Connections
IN
MM
2.5
65
3
76
4
100
6
152
6
152
6
152
8
203
8
203
(A) Overall Height
IN
MM
64
1626
68
1727
78
1981
107
2718
107
2718
131
3327
114
2896
118
2997
(B) Overall Diameter
IN
MM
62
1575
62
1575
81
2057
95
2413
95
2413
130
3302
118.5
3010
119.5
3035
(C) Overall Depth
IN
MM
134
3404
137
3480
169.9
4315.5
208.25
5289.6
182
4623
240
6096
327
8306
351
8915
(D) Flue Outlet Diameter
IN
MM
12
304
14
356
18
457
22
559
22
559
22
559
36
914
36
914
Approximate Dry Weight
IN
MM
5000
2272
7500
3409
9500
5455
12,500
5682
19,250
8750
21,700
9864
39,000
17,728
39,000
17,728
