Fulton Vertical Electric (FT-N) Thermal Fluid (hot oil) Heater - Manual (Page 99)

Fulton Thermal Corp.*Electric Thermal Fluid Heaters Manual* Version 2010-0423
Page 99
Section 6 – Product Specs & Data
Fulton Thermal Fluid Electric Heat Transfer Systems
1. General Description
a) Contractor shall furnish and install a ___________KW BTU/Hr. electric thermal fluid heat
transfer system per plans. The system shall be "Fulton" as manufactured by Fulton
Thermal Corporation, Pulaski, New York.
b) The system shall be a complete package including a vertical jacket type heater;
combination expansion deaerator thermal buffer tank to allow for expansion of thermal
fluid during heat up to operating temperature and to prevent oxidation of the thermal fluid
during operation, even when tank is vented to atmosphere; for operating temperatures up
to 650°F complete with instrumentation and controls.
2. Heater Size & Operating Temperature
a) The heater shall produce a minimum of ______ BTU/Hr. output as measured at the
thermal fluid outlet. The heater shall _________ KW and be supplied complete with
control panel and all required safety devices for a maximum operating temperature of
_______°F (standard 650°F max). It shall have a flow rate of ______GPM and an
element voltage of ______ with a control voltage of ________.
3. Heater Design
a) The heater shall be of a vertical, annular shell type and the pressure vessel construction
shall be carbon steel ASME SA-53B/106B, SA-285C and SA-516 GR 70 with a design
pressure of 150 PSI (trimmed at 100 PSI) standard at 700°F. Test pressure will be per
ASME Code Section I and the heater shall bear the ASME stamp. The heater shall be
insulated with 4” of high temperature glass fiber insulation wrapped by a neatly finished
stainless steel jacket. It shall be completely factory piped, wired and tested. Thermal
efficiency shall be 96% minimum.
b) The following instrumentation/controls/safety devices shall be supplied as a minimum
requirement:
1. High temperature Indicator/Controller - Yokogawa
2. High temperature safely switch for shutdown - United Electric
3. Heater operation interlock with circulation pump.
4. High system pressure switch for complete shutdown – Danfoss
5. Low system pressure switch for complete shutdown – Danfoss
6. Expansion tank low level switch for shutdown - Square D
7. Heater inlet pressure gauge – Fulton
8. Pump supply (Vacuum) gauge – Fulton
