Fulton Vertical Electric (FT-N) Thermal Fluid (hot oil) Heater - Manual (Page 17)

Fulton Thermal Corp.*Electric Thermal Fluid Heaters Manual* Version 2010-0423
Page 17
a) Free standing figures take the weight of the heater alone into consideration. Floor
loadings for skid mounted units vary with configuration.
Model Free-Standing Skid-Mounted
FT-0075N 400 lbs/ft2 150 lbs/ft2
FT-0150N 300 lbs/ft2 150 lbs/ft2
FT-0225N 300 lbs/ft2 150 lbs/ft2
FT-0300N 300 lbs/ft2 150 lbs/ft2
FT-0375N 300 lbs/ft2 150 lbs/ft2
FT-0430N 300 lbs/ft2 150 lbs/ft2
FT-0640N 300 lbs/ft2 200 lbs/ft2
FT-0860N 300 lbs/ft2 200 lbs/ft2
FT-1070N 200 lbs/ft2 200 lbs/ft2
FT-1290N 200 lbs/ft2 150 lbs/ft2
FT-1500N 200 lbs/ft2 150 lbs/ft2
FT-1720N 200 lbs/ft2 150 lbs/ft2
6. Minimum Clearance for Element Removal
Model Inches Meters
FT-0075N 46 1.2
FT-0150N 46 1.2
FT-0225N 46 1.2
FT-0300N 46 1.2
FT-0375N 46 1.2
FT-0430N 66 1.7
FT-0640N 66 1.7
FT-0860N 66 1.7
FT-1070N 66 1.7
FT-1290N 66 1.7
FT-1500N 66 1.7
FT-1720N 66 1.7
a) All heaters will also require a minimum clearance overhead for personnel access and
element removal. In cases where the available height is insufficient, a roof or ceiling trap
might be considered.
b) Pipes should not be run within ten inches of any control cabinets or combustible material.
c) Failure to provide suitable and safe access at the time of commissioning may cause
delays, as our Service Engineers are instructed not to commence commissioning if
hazardous conditions exist.
