Installation – Fulton Vertical Tubeless (FT-A) Thermal Fluid (hot oil) Heater User Manual
Page 11
Questions? Call (315) 298-5121, or visit us online at www.fulton.com
SECTION 2
FTA-IOM-2013-0227
INSTALLATION
2-5
TABLE 1 - SPECIFICATIONS - VERTICAL TUBELESS THERMAL FLUID HEATER
Model FTA
0200
0380
0520
0690
1050
1740
Heat Output
1000 BTU/HR
1000 KCAL/HR
207
52
348
88
519
131
693
175
1052
265
1736
437
Thermal Fluid Content
GAL
LITERS
23
87
38
144
45
170
65
246
98
371
117
443
Recommended Flow Rate
GPM
M3/HR
90
21
90
21
125
28
125
28
150
34
200
46
Typical Circulating Pump
Motor
HP
KW
10
7.5
10
7.5
15
11.2
15
11.2
15
11.2
20
14.9
Typical Burner Motor
HP
KW
.33
.248
.33
.248
.33
.248
.75
.56
.75
.56
1.5
1.1
Fuel Consumption @ Full
Output No.2 Oil
GPH
LITER/HR
2.2
8.3
3.2
11.9
4.7
17.8
6.7
25.4
9.4
35.6
15.8
60
Natural Gas
FT3/HR
M3/HR
259
7.2
435
12.2
649
18.4
866
24.2
1315
36.8
2170
60.8
TABLE 2 - DIMENSIONS-VERTICAL TUBELESS THERMAL FLUID HEATER (SEE FIGURE 2)
Model FTA
0200
0380
0520
0690
1050
1740
Heater Inlet/ Outlet Connections
IN
MM
1.5
38
1.5
38
2
51
2
51
2
51
2.5
64
(A) Overall Height
IN
MM
69
1752
75
1905
85
2159
86
2185
86
2185
110
2794
(B) Overall Width
IN
MM
29
737
31
787
33
838
38
965
46
1168
46
1168
(C) Overall Depth
IN
MM
43
1092
45.5
1156
46
1168
56
1432
64
1626
64
1626
(D) Flue Outlet Diameter
IN
MM
6
152
6
152
8
203
10
254
12
305
12
305
Approximate Dry Weight
LB
KG
1850
840
2,100
955
2300
1045
3400
1540
4400
1995
7200
3275
Notes:
Specifi cations and Dimensions are approximate. Consult factory for model specifi c electrical requirements. We reserve the
right to change specifi cations and/or dimensions without notice.
