RATAmation v2.0 User Manual Perma Pure LLC
Phone (732) 244-0010
www.permapure.com
Sept. 2012 32
The EPA specified ranges are used to show warnings for selection of calibration gas that may not
be in the correct range for the selected calibration. Warnings are also displayed when the High
cal gas is changed due to the fact that the High Cal gas sets the span value for measurements.
There are two buttons, “OK” and “Undo”, near the editing fields.
“OK” Button - will replace the current grid information with the data currently in the edit
fields. The new data will be placed into the grid but not stored to the configuration file.
“Undo” Button - will discard changes and replace the values with the information in the
grid for the current line being edited.
There are three buttons below the grid.
Cancel – Restores the information shown in the grid to the last values stored as the
configuration information on a disk drive.
Accept – Saves the current information contained in the grid to the configuration file stored
on the disk drive.
Exit – Closes the Analyzer Input Configuration screen.
The “X” on the screen will also close the screen.
When the screen closes the grid information will be compared to the current configuration
information stored on the disk drive. If there are any differences the program will prompt to save
or discard changes.
Located at the top of the screen are two buttons.
The ‘Display Gas Advisor’ opens a screen that will display the EPA specified calibration ranges
for each analyzer at the required levels. The ‘Gas Advisor’ screen creates the information for the
ranges from the data stored on the disk. The ranges required will not reflect changes made in the
‘Cal Gas Usage’ screen until the changes are saved to the disk through the ‘Accept’ button.
The ‘Clear Gas Usage’ will clear all cal gas verse analyzer correlations.
