“Specific Test” from Test Sub Menu from Main Menu (Figure 11)
Initial Error Cal – Displays screen to perform the direct analyzer calibration.
Summary report data is stored as the initial error calibration.
Pre Run Cal - Displays screen to perform the system analyzer calibration.
Summary report data is stored as the Pre Run Cal for the next run.
Run – Displays screen to perform run.
Post Run Cal – Displays screen to perform the system analyzer calibration.
Summary report data is stored as the Post Run Cal for the current run and the Pre
Run Cal for the next run.
Final Error Cal – Displays screen to perform the direct analyzer calibration.
Summary report data is stored as the final error calibration.
Figure 12
“Manual Control” Sub Menu from Main Menu (Figure 12)
Blowback – Switches on Blowback relay of the flow drawer for 30 seconds.
The relay turns off automatically.
Relay 1 - Toggles Relay 1 On and Off. Menu item checked when relay on.
Relay 2 - Toggles Relay 2 On and Off. Menu item checked when relay on.
Relay 3 - Toggles Relay 3 On and Off. Menu item checked when relay on.
