The calibration limits are based on the span gas used for cal.
Analog Span- Engineering value of the highest analog input for the analog input module at
100% input. A 4/20 mA module will display this value at 20mA input, 0/10 VDC.
at 10 VDC, 0/5 VDC at 5 VDC. For example: an analyzer has an output of 0 to 5
VDC that represents 0 to 500 PPM and is connected to a 5VDC input module.
The value 500 is entered as the Full Scale Value. In the same application except
the module accepts 10 VDC then Full Scale Value will be 1000ppm.
Units – descriptive text of the scale units.
The field will accept Alt character codes. For example to display the degree
symbol (°), hold the ‘ALT’ key and enter 248 on the numeric keypad. When the
‘ALT’ key is released the symbol will be displayed.
Alt character code values are available from many reference sources.
Train – Train 1 / Train 2
The default value is Train 1.
Allows for multiple streams.
Long Cal Time- When checked the time periods and readings required are calculated
using the long response time instead of the direct or system response
times. This value is evaluated for each analyzer separately. When multiple
analyzers are active at the same time, any analyzer in the group with ‘Long Cal
Time’ checked will set the time for the entire group. The response times are set in
the Program Set Up screen. The Long Cal Time is checked only when analyzer
requires a longer response period to obtain an accurate result.
There are three buttons below the grid.
Cancel – Restores the information shown in the grid to the last values stored as the
configuration information on a disk drive.
Accept – Saves the current information contained in the grid to the configuration file store
on the disk drive
Exit – Closes the Analyzer Input Configuration screen.
The “X” on the screen will also close the screen
