Introductory Rotational Apparatus

012-03051F

26

average

Object

Mass (g)

Force (N)

R (m)

alpha (rad/s/s)

Base Plate

25.5700

0.2506

0.015

0.4111

46.3500

0.4542

0.015

0.8646

87.2300

0.8549

0.015

1.6976

117.4100

1.1506

0.015

2.3157

157.7600

1.5460

0.015

3.1756

191.7200

1.8789

0.015

3.8850

B.P. + ring

25.5700

0.2506

0.015

0.2858

B.P. + disk

25.5700

0.2506

0.015

0.1917

B.P. + bar

25.5700

0.2506

0.015

0.2694

B.P.

25.5700

0.2506

0.015

0.4472

25.5700

0.2506

0.020

0.6253

25.5700

0.2506

0.025

0.7704

Notes – on Analysis

The acceleration is directly proportional to the radius for a
constant force.

The acceleration is directly proportional to the force for a
constant radius.

Increasing the mass by adding another disk increased the
rotational inertia and decreased the acceleration.

Ranking the three objects in increasing order of inertia would
give: ring, bar, then disk. This is misleading, because for
objects of the same mass and radius the ring would have the
highest inertia. The lower inertia of the ring is due to its
smaller radius, not its shape.

Notes

The assumption that the force on the turntable equals mg is valid
only for small masses and acceleratons. Using larger masses will
lessen your accuracy in this experiment. If the masses used are too
small, then the friction in the device may be proportionally large
enough that it causes errors as well. Generally, keep the falling mass
between about 20 and 200 grams.

With the assumption mentioned, this lab is essentially identical to
experiment 1.

0

0.5

1

1.5

2

2.5

3

3.5

4

0

20 40 60 80 100 120 140 160 180 200

angular acceleration

mass (g)

Acceleration vs. Mass

radius = 1.5 cm

Acceleration vs. Mass

radius = 1.5 cm

0

0.2

0.4

0.6

0.8

1

0

0.005

0.01

0.015

0.02

0.025

0.03

angular acceleration

radius (cm)

Angular Acceleration v. Radius

mass = 25.57g

Angular Acceleration v. Radius

mass = 25.57g
