CC6566 - CC6566-3 Concrete Saw Manual
Specifications
Table 1: Saw Specifications
Maximum Cutting Depth 17-3/4” with 42” blade
Blade Shaft Diameter 2”
Arbor Diameter 1” with driven pin
Blade Shaft Bearings Oil Filled
Blade Shaft Drive 10 V-Belts
Blade Mounting Right or left
Blade Raise/Lower Electro-hydraulic pump
Blade Coolant Dual multi-spray water tubes
Blade Guard Attachment Slip-on up to 30”; bolt-on for 36” and 42”
Front Wheel Dimensions 8” Ч 3” Ч 1 5/8”
Rear Wheel Dimensions 10” Ч 3” Ч 2”
Handlebars Two-position tilt
Transmission Eaton model 10
Drive Speed 0-200 ft/min
Electric Start Standard
Hour Meter Standard
Amp Meter Warning light
Fuel Capacity Nine gallons
Tachometer Standard
Cutting Depth Indicator
Standard
Quick Disconnect Blade Flanges Standard
Frame Lift
Standard
Quick Release Rear Wheels Standard
Uncrated Weight
(add 100 lb for crated weight)
1,844 – 1,901 lb
Table 2: Engine/Motor Specifications
Manufacturer Kubota
Model V2607
H.P. (SAEJ1349) (HP / rpm)
66 HP / 2700 RPM
Fuel Type Low sulfur/ultra-low sulfur diesel fuel
Cylinders 4
Note: Refer to the engine manual for additional engine information and
specifications.
13
