EP1000A E-Port Instruction Manual

14 Installation

2.3.2 Mounting Procedures

2.3.2.1 Wall Mounting

If wall/DIN rail mounting brackets were specified when the E-Port unit was ordered, the following items are
supplied for mounting the unit:

To fasten the E-Port unit to a wall or other flat surface, use this procedure. (Note: Set aside the DIN rail
clips, as they will not be used.)

1.

Verify that you have both a left and right aluminum bracket. (Place them side by side, with the
flanges pointing away from each other. The tops of the center screw holes in the flanges
should be pointing in the same direction (

Figure 2-1

).

2.

On the E-Port unit, remove the two screws on one side.

3.

Align the screw holes in the mounting bracket plate with the screw holes in the side of the E-
Port unit.

4.

Place the screws in the holes and fasten, attaching the mounting bracket to the E-Port unit.

5.

Repeat Steps

2

through

4

on the other side of the E-Port unit, using the other mounting

bracket.

6.

Use the holes in the flanges to attach the unit directly to the wall, using the screws provided.

2.3.2.2 DIN Rail Mounting

If wall/DIN Rail mounting brackets were specified when the E-Port unit was ordered, the following items
are supplied for mounting the unit:

To attach the E-Port to a DIN rail, use the following procedure.

Part Number

Description

122C100U01

Mounting hardware package, bagged. This includes:
1 pair (left and right) of aluminum brackets, black
1 pair (identical) of DIN rail clips
4 screws

Part Number

Description

122C100U01

Mounting hardware package, bagged. This includes:
1 pair (left and right) of aluminum brackets, black
1 pair (identical) of DIN rail clips
4 screws
