Chapter 6-injection sequence – Magnum Venus Plastech INNOVATOR II CONTROL UNIT User Manual
Page 33
INSTALATION/OPERATIONS MANUAL
INNOVATOR II
MAGNUM VENUS PLASTECH
REV 1.40
MAY 2012
PAGE 33
CHAPTER 6-Injection Sequence
After the unit has been setup, tested and adjusted, the injection sequence is very simplistic.
1. Start the unit in recirculation mode, this ensures all the air is purged from the system and there are no issues
with the pumps.
2. Install accessories, PPVS, TAS etc.
3. Set the predetermined counter to the correct stroke count.
4. Stop the recirculation sequence
5. Using the INJECT pushbutton, start the injection sequence.
6. Once the injection is done, place the discharge hose into a waste bucket and using the FLUSH pushbutton, flush
solvent thru the mix chamber and discharge hose.
Unit is now ready for the next injection cycle.
