Machine operations, Fig 4.10, Fig 4.15 – Magnum Venus Plastech INNOVATOR II CONTROL UNIT User Manual
Page 15
INSTALATION/OPERATIONS MANUAL
INNOVATOR II
MAGNUM VENUS PLASTECH
REV 1.40
MAY 2012
PAGE 15
FIG 4.10
FIG 4.15
Machine operations
Before the system can be used the air isolation sleeve-
valve must be moved to the “ON” position and the E-Stop must be
released. When air is initially supplied, all controls should automatically reset to their non-operational state.
NOTE: Residual pressures may remain in the system even though the E-Stop has been activated and the air
supply has been removed from the machine.
EMERGENCY STOP
BUTTON
PUMP PRESSURE
REGULATOR
PUMP PRESSURE GAUGE
STROKE
COUNTER
GEL ALARM
INDICATOR
CATAYLST O/P
INDICATOR
FLUSH BUTTON
MOLD PRESSURE
GUARD GAUGE
MOLD PRESSURE
GUARD REGULATOR
RESET BUTTON
CURRENT COUNT DISPLAY
PRESET COUNT DISPLAY
DIGIT LOCKOUT
DIGIT MODIFIERS
INJECTION BUTTON
STOP BUTTON
RECIRCULATION BUTTON
