bIll of materIals
POD Assemblies
item # Description Part #
4 Screw, #10-24 x .625 09079
5 Screw, #10-24 x .625 40107
8 Set Screw, M4x.7 09438
POD Internal Components
item # Description Part # (PoD1) Part # (PoD2) Part # (PoD3) Part # (PoD4) Part # (PoD5)
1 PC Board Assembly 84120 84120 84120 84120 81999-1
2 Cover Assembly 81163 81163 81163 81163 81163
3 Housing Assembly N/S* N/S N/S N/S N/S
4 Drive Assembly 81165 (Fork) 81165 (Fork) 81172 (Blade) 81172 (Blade) 81165
6 Hub Magnet Assembly N/S N/S N/S N/S N/S
7 O-Ring, Buna-N 09212 09212 09212 09212 09212
8 Screw, #5-40 x .125 09211 09211 09211 09211 09211
9 O-Ring, Buna-N or PTFE 06856 (Buna) 09151 (PTFE) 06856 (Buna) 09151 (PTFE) 06856
10 Screw, #6-32 x .375 08177 (Buna) 08177 (PTFE) 08177 (Buna) 08177 (PTFE) 08177
11 Hub Magnet Assembly 81159 81159 81159 81159 501241
12 (2) 6-32 x ¼" Earth Ground Screw 08230 08230 08230 08230 08230
