Laurel Electronics Custom ASCII Protocol For Laureate Series 2 Digital Panel Meters, Counters, Timers & L-Series Transmitters User Manual
Page 49
49
6B (L)
Config
Bit 7 6 5 4 3 2 1 0
0 Enable Adaptive Filtering
1 Disable Adaptive Filtering
0 Peak of Net Value
1 Peak of Gross Value
0
Enable Dribble
1
Disable Dribble
0
Setup Scale Method
1
Reading 2 Coordinates Method
0
Allow Negative Readings
1
Disallow Negative Readings
6D (L)
Count
Bit 7 6 5 4 3 2 1 0
0 0 0 0 No Auto-Zero
0 0 0 1 ±1 Auto-Zero
0 0 1 0 ±2 Auto-Zero
0 0 1 1 ±3 Auto-Zero
0 1 0 0 ±4 Auto-Zero
0 1 0 1 ±5 Auto-Zero
0 1 1 0 ±6 Auto-Zero
0 1 1 1 ±7 Auto-Zero
1 0 0 0 ±8 Auto-Zero
1 0 0 1 ±9 Auto-Zero
0 0 0 0
Count by 1
0 0 0 1
Count by 2
0 0 1 0
Count by 5
0 0 1 1
Count by 10
0 1 0 0
Count by 20
0 1 0 1
Count by 50
0 1 1 0
Count by 100
0 1 1 1
Count by 200
1 0 0 0
Count by 500
1 0 0 1
Count by 1000
2F (L)
Filter
Bit 7 6 5 4 3 2 1 0
0 0 0 0 Auto Filter
0 0 0 1 Batch Filter (16 Samples)
Time constant
60 Hz 50 Hz
0 0 1 0 Moving Average 0.07s 0.085s
0 0 1 1 Moving Average 0.14 0.17
0 1 0 0 Moving Average 0.28 0.34
0 1 0 1 Moving Average 0.57 0.68
0 1 1 0 Moving Average 1.13 1.36
