34 (L) Configuration Bit 7 6 5 4 3 2 1 0
0 Enable cutoff of VF totalizing
1 Totalize all VF values
0 Linear input
1 Square Root of input
0 0 Basic Counter
0 1 Extended Counter
1 0 Custom Curve #1 (for FR & VF)
1 1 Custom Curve #2 (for VF)
Display mode:
0 0 0 0 Normal, Exponential Overload
0 0 0 1 Normal, 999999 Flashing Overload
0 0 1 0 1 Right-Hand dummy zero
0 0 1 1 2 Right-Hand dummy zeros
0 1 0 0 Clock Time, Stopwatch, Multi-format
0 1 0 1 Clock Time, Stopwatch, hh.mm.ss
0 1 1 0 Remote Display, Addressable
0 1 1 1 Remote Display, Single Value
1 0 0 0 Slave Display, 1st data value of string
1 0 0 1 Slave Display, 2nd data value of string
1 0 1 0 Slave Display, 3rd data value of string
1 0 1 1 Slave Display, 4th data value of string
1 1 0 0 Masked display
33 (L) Serial Cnfg3 Bit 7 6 5 4 3 2 1 0 Transmit:
0 0 0 All active items
0 0 1 Item #1 only
0 1 0 Item #2 only
0 1 1 Item #3 only
1 0 0 Peak value only
1 0 1 All active items + Peak
0 Term chars end of all items
1 Term chars end of each item
0 Non-Latching RTS
1 Latching RTS
0 0 Std recognition char, no start/stop char
0 1 Custom recognition char, no start/stop char
1 0 Std recognition char, special start/stop char
1 0 Custom recog char, special start/stop char
0 Full Duplex
1 Half Duplex
