Bit 6 0 = Relay3 Active On 1 = Off
Bit 7 0 = Relay4 Active On 1 = Off
68 0044 Alarm
Config 4
Bits 2:0 = # Readings before Alarms 3 & 4.
000 = 1, 001 = 2, 010 = 4, 011 = 8, 100 = 16,
101 = 32 110 = 64 111 = 128
Bit 3 AL3 0 = Deviation 1 = Hysteresis
Bit 4 AL4 0 = Deviation 1 = Hysteresis
Bit 5 0 = Deviation in Menu 1 = Omitted
Rate 00-0F 00 = A&B, 01 = AOnly, 02 = Batch,
03 = A_Atot, 05 = A_Btot, 0B = A+B,
0C = A-B, 0D = A*B, 0E = A/B, 0F = A/B-1
Period 10-1E 10 = A&B, 11 = AOnly
1B = A+B, 1C = A-B, 1D = A*B, 1E = A/B
Total 20-2E 20 = Total A&B, 21 = AOnly
24 = A-B_ud, 26 = Burst=26, 27 = B_Arat,
29 = A_Bud, 2A = A_Binh, 2B = A+B, 2C = A-B,
2D = A*B, 2E = A/B
Time
Interval 41-42 41 = Time Interval A to B
42 = 1 / (A to B)
Stopwatch 50-53 50 = A to A,
51 = A to B
52 = 1 / (A to A)
53 = 1 / (A to B)
Phase 61-62 61 = 0-360
62 = -180 to +180
Duty Cycle 71 A to B
V-to-F
Signal
Conditioner XY X = 8, 4-20 mA input
X = 9, 0-1 mA input
X = A, 0-10V input
Y = 1, A only
Y = 2, Batch
Y = 3, A to A total
Y = F, 1/A
69 0045
Input
Type
Quadrature C0-C1 C0 = Total
C1 = Rate
70 0046 Setup
M = Meter
F = Function
D = Display
Bits 3:0 Ctrl In 1 Ctrl In 2 Both Reset
Hex 0 Meter Reset Function Reset MReset
Hex 1 Meter Reset Meter Hold
MReset
Hex 2 Meter Reset Peak or Valley MReset
Hex 3 Meter Reset External Gate MReset
Hex 4 Function Reset Meter Hold MReset
