- 18 -

40

0028

Deviation 4 (Lo word) (not for Scale Meter)

as displayed

41

0029

Analog Lo (Hi word)

42

002A

Analog Lo (Lo word)

2C32

Dec pt same
as displayed

43

002B

Analog Hi (Hi word)

44

002C

Analog Hi (Lo word)

2C32

Dec pt same
as displayed

* Values are for Base 1 Standard addressing. Add 1 for Base 0 PLC addressing.
** Scale = .0001 x dec value of (Hi word + Lo word)

Data Type B16

For the following, use any starting Register Address and any number of Registers.

Register Address

Dec

Hex

Register Name

Bit Significance

65

0041

Alarm Config 1

Bit 0

0 = AL1 Hi Active

1 = Lo Active

Bit 1

0 = AL1 Enabled,

1 = Disabled

Bit 2

0 = AL2 Hi Active

1 = Lo Active

Bit 3

0 = AL2 Enabled

1 = Disabled

Bit 4

0 = AL1 Non-Latched 1 = Latched

Bit 5

0 = AL2 Non-Latched

1 = Latched

Bit 6

0 = Relay1 Active On

1 = Off

Bit 7

0 = Relay2 Active On

1 = Off

66

0042

Alarm Config 2

Bits 2:0 # Readings before Alarms 1 & 2.

000 = 1, 001 = 2, 010 = 4, 011 = 8, 100 = 16,

101 = 32, 110 = 64, 111 = 128

Bit 3

AL1 0 = Deviation

1 = Hysteresis

Bit 4

AL2 0 = Deviation

1 = Hysteresis

Bit 5

0 = Deviation in Menu 1 = Omitted

67

0043

Alarm Config 3
(not applicable
to Scale Meter)

Bit 0

0 = AL3 Hi Active

1 = Lo Active

Bit 1

0 = AL3 Enabled

1 = Disabled

Bit 2

0 = AL4 Hi Active

1 = Lo Active

Bit 3

0 = AL4 Enabled

1 = Disabled

Bit 4

0 = AL3 Non-Latched 1 = Latched

Bit 5

0 = AL4 Non-Latched 1 = Latched

Bit 6

0 = Relay3 Active On

1 = Off

Bit 7

0 = Relay4 Active On

1 = Off

68

0044

Alarm Config 4
(not applicable
to Scale Meter)

Bits 2:0 = # Readings before Alarm 3 & 4

000 = 1, 001 = 2, 010 = 4, 011 = 8, 100 = 16,

101 = 32 110 = 64 111 = 128

Bit 3

AL3 0 = Deviation

1 = Hysteresis

Bit 4

AL4 0 = Deviation

1 = Hysteresis

Bit 5

0 = Deviation in Menu 1 = Omitted
