ENFORCER Long-Range Barrier Sensors
4 SECO-LARM U.S.A., Inc.
Dimensions:
2 1 /
4
”
(55mm)
1 7 /
8
”
(49mm)
2 1 /
4
”
(55mm)
1 7 /
8
”
(49mm)
2 1 /
4
”
(55mm)
1 7 /
8
”
(49mm)
2 1 /
4
”
(55mm)
1 7 /
8
”
(49mm)
26”
(66cm)
43”
(109cm)
61”
(155cm)
79”
(201cm)
E-9626-2B190Q E-9643-4B190Q E-9661-6B190Q E-9679-8B190Q
Swivel Housing:
Each sensor is built
with a swivel housing
for flexible installations
and simple alignment.
To use, twist the
beams up to 90
 .
Sample Applications:
Typical
door/window
frame
Windows Fence tops
Garages,
gates, and
walls
1. Remove cap
2. Loosen
swivel head
screw
3. Turn sensor
to desired
position
4. Tighten screw
and replace
the end cap
