SECO-LARM

®

U.S.A., INC.

INSTALLATION MANUAL

ENFORCER

®

Page 8

Curtain/Barrier Sensors Installation Manual

®

PICTN1

E-9680-10B25

--

10-Beams, 80-Inches Long, Black

E-9660-8B25

--

8-Beams, 60-Inches Long, Black

E-9644-6B25

--

6-Beams,44-Inches Long, Black*

E-9622-4B25

--

4-Beams,22-Inches Long, Black*

E-9611-2B25

--

2-Beams,11-Inches Long, Black*

*Available in White

Curtain/Barrier Sensors

(E-9622-4B25 shown)

Range: 50 ft. indoor, 25 ft. outdoor

Dimensions:

Side View

1

5

/

16

” (

33.5mm)

1

7

/

32

” (30.6mm)

7

/

8

” (

22.3mm)

3

/

4

” (19.6mm)

11.25” (29cm) -- E-9611-4x25

22.5” (57cm) -- E-9622-4x25

44.5” (113cm) -- E-9644-6x25

60.1” (153cm) -- E-9660-8B25

79” (201cm) -- E-9680-10B25

E-9611-2x25

E-9622-4x25

E-9644-6x25

E-9660-8B25

E-9680-10B25

80mA

89mA

94mA

102mA

110mA

60mA

73mA

79mA

92mA

100mA

11

1

/

4

” x 1

5

/

16

” x

7

/

8

22

1

/

2

” x 1

5

/

16

” x

7

/

8

44

1

/

2

” x 1

5

/

16

” x

7

/

8

60

1

/

8

” x 1

5

/

16

” x

7

/

8

79” x 1

5

/

16

” x

7

/

8

0.5~20mS

0.5~32.5mS

0.5~48.5mS

0.5~60mS

0.5~70mS

Specifications:

Standby -- 12~24VDC
Active -- 12~24VDC
Dimensions
Response time
Maximum range
Detection method
Output
Operating temperature
Attenuation LED

Enclosure / Case
Mounting bracket

Indoor: 50’ (16m), outdoor: 25’ (8m)
Simultaneous break of 2 adjacent beams or any single beam (programmable)
NO./NC. relay output, 1A @ 12 ~ 24VDC
-49 ~131 F (-45 ~55 C)
(On): powered, aligned properly*
(Flashing): beam is broken or unaligned*
(Off): no power*
*Depending upon how programmed
IP65 / Al alloy
Included

CurtainSensor032309b.pmd

WARRANTY:

This SECO-LARM product is warranted against defects in material and workmanship while used in

normal service for a period of one (1) year from the date of sale to the original consumer customer. SECO-LARM’s obligation is

limited to the repair or replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM.

This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect, repair, or

alteration, improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines that such

equipment is not operating properly as a result of causes other than defects in material and workmanship.

The sole obligation of SECO-LARM, and the purchaser’s exclusive remedy, shall be limited to replacement or repair only, at

SECO-LARM’s option. In no event shall SECO-LARM be liable for any special, collateral, incidental, or consequential personal or

property damages of any kind to the purchaser or anyone else.

NOTICE

The information and specifications printed in this manual are current at the time of publication. However, the SECO-LARM

policy is one of continual development and improvement. For this reason, SECO-LARM reserves the right to change

specifications without notice. SECO-LARM is also not responsible for misprints or typographical errors.
Copyright © 2009 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be reproduced or copied, in whole
or in part, without the written permission of SECO-LARM.

SECO-LARM

®

U.S.A., Inc.

16842 Millikan Avenue, Irvine, CA 92606
Tel: 800-662-0800 / 949-261-2999 Fax: 949-261-7326

Website: www.seco-larm.com
E-mail: [email protected]
