P A R T S L I S T
312HM - Single Channel Radio Receiver
1941240D - Chain #41 (per 10' box)
Q006 - PC Board Nuts (Set)
Q027 - Motor Capacitor
Q029 - Limit Switch (Sold Individually)
Q067 - Chassis
Q068 - Electronic Box
Q070 - Drive Sprocket
Q073 - Gear Box Cover Post 1/99
Q074 - Coupling (3/4 x 5/8) 3 pcs
Q075 - Limit Switch Ball Bearing
Q076 - Turn Buckle
Q07710 - 10' Track, One Pair
Q07712 - 12' Track, One Pair
Q07714 - 14' Track, One Pair
Q078 - Trolley Wheel Shaft
Q079 - Trolley Body
Q080 - Trolley Latch
Q081 - Limit Switch Bolt
Q082 - Limit Switch Nuts
Q083 - Trolley Wheels
Q084 - Emergency Key Release
Q085 - Trolley Cover
Q086 - Retaining Spring Clip
Q087 - Emergency Pulling Ring Q088 - Gate Arm
Q089 - Trolley Body Assembly
Q090 - Plastic Plug
Q091 - Idler Sprocket
Q092 - Rubber Isolator
Q093 - Idler Sprocket Cover
Q094 - Arm Bracket
Q095 - Arm Bushing
Q096 - Header Bracket
10-10203 - Curved Arm Assembly
10-10204 - Alternate Mounting Bracket
178B34 - Straight Arm Assembly
Q097 - Mounting Plate
Q118 - Manual Release Key
Q170 - Electronic Box Cover (Black)
Q200 - Chain Coupling/Release
Q248 - Gear Reducer (40:1) Post 2/99
Q250 - 1/2 HP Electric Motor Post 2/99
Q400E-1 - OmniControl Board
Q404 - Omni Alarm
Q410 - Surge Suppressor Terminal Block
Q620 - Motor Harness Omni
APBS1 - Reset Button
40-3505 - U.L. Warning Sign (not shown)
M A I N T E N A N C E
1. Make sure the gate operates smoothly without the operator.
2. Make sure the gate track runs smoothly.
3. For chain maintenance, you can adjust the turn buckle.
4. Check external entrapment protection systems monthly for proper operation.
