O P T I O N A L R E L A Y A D A P T E R C O N N E C T I O N
CENTER
SAFETY
EXIT
CENTER
SAFETY
EXIT
FIRE
DEPT.
1
3
STRIKE
OPEN
RADIO
RECEIVER
TIMER
SYSTEM ON
EXIT
LOOP
ALARM
SENSOR
REVERSE
SENSOR
OPEN
STOP
CLOSE
SAFETY
LOOP
CENTER
LOOP
GATE
LOCKED
60
POWER
OVERLOAD
OFF
W4
OPEN LEFT
DC-BACKUP
ALARM
SENSOR
OPEN RIGHT
3
SENSORS
RESET
MOTOR
1
3
1
3
COMMAND
PROCESSED
ON
G B
MS LINK
A
MADE IN USA
Connection of a Solenoid or Magnetic Lock can be made
using the “Optional” Relay Adapter Module.
Relay Contact Rating
2 Amp - 125 AC/DC
2 Amp switching load capability
Normally Closed
Normally Open
Optional Relay Adapter Module
Optional Relay Adapter Module
Common
Common
Plug-In
Transformer
Solenoid Lock
Solenoid Lock
Ground
To OmniControl Board
To OmniControl Board
Ground
Power
Magnetic Lock
Plug-In
Transformer
Magnetic
Lock
Ground
Ground
Power
Relay Light On:
Indicates
actuation of OmniControl board
Relay Module LEDs
Power Light On:
Indicates
power is being received
See Accessories page for Relay Adapter Module
17
