11
A D J U S T I N G T R A V E L I N G D I S T A N C E
Before Adjusting, Do the Following:
1. Disconnect power to the operator.
2. Push the limit nut lock plate inward. Roll the nut to the direction desired.
3. Place the plate back in the notch.
4. Reapply power to operator.
5. If further adjustment is needed, repeat the process.
Push Plate
STEP 8
