BYAN SYSTEMS, INC.
Automated Gate and Access Control Products
413 Linden • Lusk, WY 82225 • (800) 223-2926
6
INSTALLING THE OPERATOR
! ADVISORIES!
A. THIS LINEAR ACTUATOR MUST ME MOUNTED SO THE PISTON FULLY EXTENDS
AND FULLY RETRACTS. WHEN FULLY RETRACTED THERE SHOULD BE 1/8 INCH
PISTON LEFT OUT OF THE FRONT.
B. THIS LINEAR ACTUATOR HAS AN OFFSET BETWEEN THE FRONT AND REAR
MOUNTING BRACKET. THE FRONT BRACKET IS ABOUT 5/8 OF AN INCH LOWER
THAN THE FRONT BRACKET; REVIEW THE BRACKET ALIGNMENT DETAIL FOR
THE OFFSET DIMENSION. THE FRONT BRACKET HAS THE TALLER SHOULDER.
1. SCRIBE A LINE FROM THE HORIZONTAL SUPPORT OR DESIRED HEIGHT FOR THE
OPERATOR ON THE GATE LEAF ONTO THE GATE POST.
2. MEASURE FOR THE OFFSET DESCRIBED IN THE ADVISORY #B AND SCRIBE
ANOTHER LINE.
3. CUT THE REAR MOUNTING BRACKET IN ACCORDANCE WITH THE DIMENSIONS
SPECIFIED ON THE MOUNTING GEOMETRY DETAIL.
4. WELD THE REAR MOUNTING BRACKET TO THE GATE POST.
5. DETERMINE THE “C” DIMENSION AND CUT THE FRONT MOUNTING BRACKET TO
THE PROPER LENGTH.
6. EXTEND THE PISTON TO FULLY EXTENDED POSITION FOR INWARD SWING
GATES. THIS CAN BE ACHIEVED BY TEMPORARILY CONNECTING THE CONTROL
PANEL TO THE OPERATOR AND USING THE MOTOR TO EXTEND THE PISTON,
PRODUCING 9 7/8” OF PISTON. IT IS VERY IMPORTANT WITH THE “800A/900A”
THAT THE PISTON “BOTTOMS OUT IN BOTH DIRECTIONS”.
7. SCREW THE “I” BOLT INTO THE END OF THE PISTON 1/2 TO 3/4 OF THE LENGTH OF
THE THREADS. ATTACH THE FRONT BRACKET TO THE OPERATOR.
8. ATTACH THE OPERATOR TO THE REAR MOUNTING BRACKET.
9. WITH THE GATE IN THE FULL CLOSED POSITION, LEVEL THE OPERATOR AND
SCRIBE THE LOCATION FOR THE FRONT MOUNTING BRACKET.
10. REMOVE THE FRONT MOUNTING BRACKET FROM THE FRONT OF THE GATE
OPERATOR AND WELD IT TO THE GATE LEAF AT THE SCRIBED LOCATION.
11. ATTACH THE OPERATOR TO THE FRONT MOUNTING BRACKET.
