BYAN SYSTEMS, INC.
Automated Gate and Access Control Products
413 Linden • Lusk, WY 82225 • (800) 223-2926
11
MOUNTING DIMENSIONS
800A/900A I/O SERIES GATE OPERATOR
4” GATE W/ 2” GATE LEAF
INWARD SWING
DON’T USE THESE DIMENSION FOR LONG OPERATORS PLEASE CALL FOR
CORRECT DIMENSIONS
DEGREE A B C
70 7-1/4 2-1/4 2-3/4
75 6-7/8 2-1/4 2-3/4
80 6-3/8 3 2-3/4
85
6 4-1/4 2-3/4
90 5-5/8 4-1/8 2-3/4
95 5-3/8 4-1/2 2-3/4
*100 4-3/4 4-3/4 2-3/4
*105 4-1/8 4-3/8 2-3/4
110 N/A N/A N/A
6” GATE W/ 2” GATE LEAF
INWARD SWING
DON’T USE THESE DIMENSION FOR LONG OPERATORS PLEASE CALL FOR
CORRECT DIMENSIONS
DEGREE A B C
70 7-1/4 2-1/4 2-3/4
75 6-7/8 2-1/4 2-3/4
80 6-3/8 3 2-3/4
85
6 4 2-3/4
90 5-5/8 4-1/2 2-3/4
95 5-3/8 4-1/2 2-3/4
*100 5-1/8 4-3/4 2-3/4
*105 4-3/8 4-3/8 2-3/4
110 N/A N/A N/A
OUTWARD SWING
DON’T USE THESE DIMENSION FOR LONG OPERATORS PLEASE CALL FOR
CORRECT DIMENSIONS
DEGREE A B C
70 7-1/2 3-1/2 3
75 6-3/4 4 3
80 6 4-1/2 3
85 5-1/2 4-1/2 3
90 4-3/4 5 2-3/4
95 4-1/2 4-3/4 2-3/4
100 4-3/8 4-1/2 2-3/4
105 3-1/8 4-1/2 2-1/2
*110 3-1/4 4-7/8 2-1/2
*WITH THE GATE MOUNTED ON THE CENTERLINE OF THE GATE POST THESE MOUNTING
DIMENSIONS WILL BE VERY CLOSE TO THE GATE POST.
FOR OTHER DIMENSIONS PLEASE CALL BYAN SYSTEMS.
