BYAN SYSTEMS, INC.
Automated Gate and Access Control Products
413 Linden • Lusk, WY 82225 • (800) 223-2926
9
MANUAL BYPASS
THE MANUAL BYPASS VALVE IS FOR THE ABILITY TO RELEASE THE OPERATOR
IN THE EVENT OF A POWER FAILURE OR MALFUNCTION. IT IS LOCATED UNDER
THE KEYED CAP ON TOP OF THE OPERATOR. A METRIC ALLEN WRENCH IS
SUPPLIED IN THE CAP TO RELEASE THE BYPASS VALVE. TURN THE VALVE
COUNTER CLOCKWISE UNTIL THE OPERATOR RELEASES. WHEN TIGHTENING
THE BYPASS VALVE IT MUST BE TIGHT IN ORDER TO PREVENT FLUID OR
PRESSURE ESCAPING BACK INTO THE CHAMBER.
PLACARDS AND SAFETY EQUIPMENT
THE PLACARDS SHOULD BE INSTALLED (ONE ON EACH SIDE OF THE GATE) SO
THAT THEY ARE VISIBLE AS ANYONE THAT APPROACHES THE GATE. THE
SAFETY EQUIPMENT SHOULD BE TESTED BEFORE LEAVING THE GATE SITE.
