Controlled Products Systems Group 800IOL - Manual (Page 2)

BYAN SYSTEMS, INC.
Automated Gate and Access Control Products
413 Linden • Lusk, WY 82225 • (800) 223-2926
1
TABLE OF CONTENTS
DESCRIPTION PAGE NO.
USAGE CLASSES FOR VEHICULAR GATE OPERATOR 2
TECHNICAL DATA ABOUT THE OPERATOR 3
BEFORE YOU INSTALL 4
DURING INSTALLATION PROCEDURES 4
INSTALLATION COMPLETION/FOLLOW UP 5
INSTALLING THE OPERATOR 6
PURGING THE OPERATOR 7
PRESSURE ADJUSTMENTS 8
HYDRAULIC FLUID 8
MANUAL BYPASS 9
MOUNTING GEOMETRY 10
MOUNTING BRACKET LOCATION 11
FRONT MOUNTING DETAIL 12
WIRING THE CONTROL AND ACCESSORIES 13
CONNECTING THE OPERATOR 19
LOOP CONNECTORS 21
WARRANTY 26
END USER SAFETY 27
CUSTOMER ACKNOWLEDGMENT 29
