RECOMMENDED WIRE SIZES
HIGH VOLTAGE A.C.
14 AWG TO 400 FEET
12 AWG TO 650 FEET
10 AWG TO 1000 FEET
8 AWG TO 1650 FEET
6 AWG TO 2650 FEET
LOW VOLTAGE A.C.
18 AWG TO 100 FEET
16 AWG TO 170 FEET
14 AWG TO 270 FEET
12 AWG TO 430 FEET
10 AWG TO 690 FEET
8 AWG TO 1100 FEET
LOW VOLTAGE D.C.
20 AWG TO 400 FEET
18 AWG TO 700 FEET
16 AWG TO 1100 FEET
14 AWG TO 1700 FEET
12 AWG TO 2800 FEET
10 AWG TO 4500 FEET
NOTE:
THESE WIRE SIZES ARE ONLY GENERAL RECOMMENDATIONS. FEDERAL, STATE
AND LOCAL CODES ALWAYS TAKE PRECEDENCE. CONSULT THE N.E.C. OR LOCAL
AUTHORITY HAVING JURISDICTION IF YOU HAVE WIRING CONCERNS
.
