SECOND MOTOR CARD T2M
CHARACTERISTICS:
THIS CARD IS SUITABLE FOR DRIVING A SECOND MOTOR THROUGH THE
CONTROL UNIT, SELECTING THE OPENING DELAY TIME AND THE CLOSING
DELAY TIME BETWEEN THE TWO MOTORS.
THE LIMIT SWITCHES OF THE SECOND MOTOR SHOULD BE CONNECTED TO THIS
CARD. THESE SIGNAL INPUTS ARE OPT-COUPLED TO PREVENT MALFUNCTION
DUE TO INTERFERENCE OR ATMOSPHERIC DISTURBANCES.
THE CONTROL UNIT POWERS THE CARD. THE CARD HAS TO BE INSERTED IN THE
CONNECTOR MARKED AS “T.2 MOTOR” ON THE MAIN BOARD OF THE CONTROL
UNIT.
IN THE OPENING OPERATION, MOTOR 1 ACTS FIRST AND IN THE CLOSING
OPERATION, MOTOR 2 ACTS FIRST.
ADJUSTABLE TIMERS:
DESCRIPTION MINIMUM MAXIMUM
LEFT (MOTOR 1) 0 SECONDS 15 SECONDS
RIGHT (MOTOR 2) 0 SECONDS 15 SECONDS
TERMINAL BOARD:
OPERATION TERMINALS: (FROM TOP TO BOTTOM).
3 OPEN LIMIT SWITCH MOTOR 2 (NORMALLY CLOSED).
2 CLOSE LIMIT SWITCH MOTOR 2 (NORMALLY CLOSED).
1 COMMON LIMIT SWITCH MOTOR 2.
