DIP SWITCH ASSEMBLY OPERATION MODE SELECTION;
No. OPTION ON OFF
1 REVERSING STROKE FUNCTION
(OPERATOR FIRST WILL CLOSE FOR 1 SECOND)
ACTIVE INACTIVE
2 STEP-BY-STEP FUNCTION* ACTIVE INACTIVE
3 AUTOMATIC CLOSING FUNCTION ACTIVE INACTIVE
4 REVERSING BUTTON IS NOT
OPERATIVE DURING OPENING ACTIVE INACTIVE
5 CLOSING ORDER BY CARS SAFETY CONTACT ACTIVE INACTIVE
6 SEE NOTE BELOW REF JP1 -------------- --------------
7 CARS SAFETY CONTACT IS
OPERATIVE DURING OPENING ACTIVE INACTIVE
*STEP-BY-STEP IS THAT EACH ACTIVATION OF THE REVERSE BUTTON WILL STOP THE
GATE BEFORE CHANGING DIRECTION.
NOTE: THERE IS A JUMPER JP1 (BELOW THE REMOTE CONTROL CARD
CONNECTOR) THAT CAUSES THE SELECTABLE OPTION No. 6 IN THE FOLLOWING
MANNER:
JP1 OPEN:
No. 6 ON
IN THE POWER ON STATE, UNIT WILL DO A CLOSING
FUNCTION
.
OFF IN THE POWER ON STATE, UNIT WILL DO AN OPENING
FUNCTION.
JP1 CLOSED:
IN THE POWER ON STATE, THE DOOR REMAINS PAUSED. IN
THIS CASE, THE SWITCH No. 6 CONTROLS THE FUNCTION OF
THE TRAFFIC LIGHTS.
ON THE TRAFFIC LIGHTS CARD WILL ACT AS A FLASHING LIGHT
CARD (UPPER RELAY) AND A GARAGE LIGHT CARD (LOWER
RELAY).
OFF THE TRAFFIC LIGHTS CARD WILL ACT AS GREEN AND RED
LIGHTS.
