CLOSING BUTTON:
USED ONLY TO CLOSE THE GATE.
STOP BUTTON:
(NORMALLY CLOSE CONTACT), STOPS THE GATE IN OPENING/CLOSING.
THREE ADJUSTABLE TIMES
BLUE TIMER:
OPENING TIMER ONLY CONTROLS THE OPENING TIME BETWEEN 3 TO 30 SECONDS.
RED TIMER:
CLOSING TIMER ONLY CONTROLS THE CLOSE TIME BETWEEN 3 TO 30 SECONDS.
GREEN TIMER:
AUTOMATIC CLOSE TIMER WHEN THE GATE IS COMPLETELY OPEN THE TIMER IS
ACTIVATED AND WILL AUTOMATICALLY CLOSE AFTER THE PROGRAMMED TIME.
NOTE: BUILT IN 2 SEC. TIMER TO STOP GATE BEFORE REVERSING OPERATION OCCURS.
OPEN/CLOSE LIMIT SWITCHES;
THEY STOP THE OPENING AND/OR CLOSING OPERATION. MUST REMOVE THE TWO
JUMPER WIRES FROM TERMINAL 11 TO 12 AND 13 IF USED.
ENTRAPMENT SAFETY CONTACT:
IF ACTIVATED, THE RESULT IS REVERSING THE MOVEMENT IN BOTH OPENING AND
CLOSING FOR 2 SECONDS. THEN STOPS, IF THE SAFETY CONTACT IS STILL ACTIVE THE
ALARM WILL SOUND.
SAFETY REVERSING CONTACT:
THE RESULT IS REVERSING BACK TO OPEN WHILE THE GATE IS CLOSING, NOT ACTIVE
WHEN OPENING.
POWER OUTPUT:
YOU CAN CONNECT MOTORS UP TO HP
TIMER TABLE:
COLOR DESCRIPTION MINIMUM MAXIMUM
GREEN AUTOMATIC CLOSING TIME 1 SECOND 2 MINUTES
BLUE OPENING TIME 3 SECONDS 30 SECONDS
RED CLOSING TIME 3 SECONDS 30 SECONDS
