25 FAAC MODEL 844 Slide Gate Operator
POS. P/N DESCRIPTION
31 702705 NUT WITH LOCKING WASHER M4
32 701000 TCEI 4X 25 5931 12 K
33 752207 LUG CEMBRE BF-M5
34 703007 WASHER 5 6592 R40 Z
35 701367 TCIC 5 X 10 7687/DIN7985 4,8 Z
36 707010 BEARING 6204-Z 20-47-14
37 7269185 SL.G.O. BEARING SPACER
38 445842 ROTOR WITH CLUTCH
39 7310275 FRICTION DISK
40 7093105 SMIM 10X30X4.5 GASKET
41 7226605 MAGNETIC DISK 746/844
42 7210125 CLUTCH ADJUSTM. SPRING
43 7090030015 GASKET OR 6.75X1.78 ( 106)
44 7181935 PIN FOR CLUTCH ADJUST. 746/844 R
45 704008 CIR CLIP E15 7435
46 7049125 GASKET ADJUSTMENT RING NUT
47 7090410025 GASKET OR 42.52X2.62 (3168)
48 704005 CIR CLIP E24 7435
49 7061185 PIN 5 X 40 M6 UNI 100 C6
50 7310125 744-746-842-844 FRICTION DISK
51 7181995 MOTOR SHAFT 844 ER
52 63000355 746/844 STROKE END UNIT
53 701119 TE 10X16 UNI 5739 10.9 Z
54 7030185 WASHER 10,5X35X4 CAT.A Z
55 701007 CAP SCR.SOCK.HEAD 5X16 8G Z
56 71707615 SIDE FLANGE 820-860
57 7094085 GASKET LATERAL FLANGE 820-860
58 7093005 GASKET FOR MOTOR SHAFT A 25407
59 7070111 BEARING 6205 25-52-15 ECON.
60 7061115 PIN 8X45 RIC.UNI EN22338
61 7180785 SLOW SHAFT 746-844
POS. P/N DESCRIPTION
62 7192075 GEAR 820-860 '92
63 704339 RING
64 7070121 BALL BEARING 6004
65 7182765 UNLOCK PIN 746-844
66 7211015 RELEASE SPRING 746-844-820-860
67 7051085 TAB 820-860
68 704009 CIR CLIP E20 7435
69 704200 RING LMKAS 42 D
70 7093055 GASKET RP 10X30X7
71 7160615 SL.G.O. 746/844 LOWER SEMI-BODY
72 7061035 PIN
73 7230145 STATOR MOUNTING ROD
74 703205 LOCK WASHER 8842 Z
75 455944 844 STATOR W/O CONNECTOR
76 7291115 LEVER FOR LOCK
77 7120885 LOCK ART.3889.3
78 7131005 KEY MOD. 3889.0913
79 409867 746-844 RELEASE LEVER UNIT
80 7019415 RELEASE LEVER SCREW
81 727197 PROTECTIVE SIDE COVER 746/844
82 701107002 HEX.HEAD 5739 8G Z 8X20
83 703002 WASHER 8 6592 R40 Z
84 722351 MOUNTING BRACKET 746/844
85 7269525 SPACER
86 3905745 SKIN PACK 746ER/844ER
87 390829 SKINPACK 746 '98 MOTOR
88 714017 HYDRAULIC OIL FAAC HP OIL LT. 1
