Pag e 4

M a y, 20 06

4 1 5 L LS Ope ra tor And

4 5 5 D C ontrol Pa ne l I nsta ll a ti on Ma nua l

T

ECHNICAL

D

ATA

T

HE

415 L LS O

PERATOR

Parameter

Measure

Voltage required, VAC

115Vac

Duty type

Residential

Maximum duty cycle (cycles per hour)

25

Maximum leaf length, ft (m)

15 (4.5)

Maximum leaf swing, deg

110

Thrust and traction, ft-lb (Nm)

221 (300)

Stroke, in. (cm)

15 (38.1)

Rod speed

, in./sec (cm/sec)

3/4 (1.85)

Operating Ambient Temperature
Deg F (Deg C)

-4 thru +131

(-20 thru +55)

Operator dimensions,
l ´ w ´ h, in. (mm)

37 x 4 x 6

(940 X 105 X 148)

Operator weight, lb (kg)

17.5

(8)

Current draw, (Amps)

2.5

Maximum amperage draw for acces-
sories, mA

.800mA

Absorbed Power (Watts)

300
