background image

P age 13

M a y, 20 06

4 1 5 L LS Ope ra tor A nd
4 5 5 D C ontrol Pa ne l I nsta ll a ti on Ma nua l

Parts List

415 L LS Operator

POS

PART NO.

DESCRIPTION

QTY

1

7220015

Rear Mounting Bracket

1

2

7284005

Rear Mounting Plate

1

3

718366

Long Pin with C Clips

1

4

7182075

Short Pin

1

5

N/A

Hex Nut

1

6

7221115

Rear Fork

1

7

716148

Rear Upper Body

1

8

428403

Manual Release Assembly

1

9

60202145 Snap Ring

1

10

60202155 Manual Release Lever

1

11

716150

Limit Switch Protective Cover

1

12

490108

Limit Switch Assembly

1

13

718354

Front Mounting Pin with C Clips

1

14

N/A

Self Tapping Screws 4.2 mm x 13 mm

7

15

728271

Front Mounting Bracket

1

16

711027

Limit Switch Adjusters Cover

1

17

490104

Cylinder

1

18

718367

Screw Drive Pin and C Clips

1

19

499399

Lower Front Cover

1

20

N/A

Self Tapping Screw 6.3 mm x 19 mm

8

21

60202225 Gear (Piston)

1

22

N/A

Self Tapping Screw 4.8 mm x 13 mm

10

23

60202165 Bushing

2

24

60202215 Gear (Motor)

1

25

770890

Motor 115Vac

1

26

709324

Gasket

1

27

60202175 Electric Cable Cover

28

716149

Rear Body Lower Half

29

2705

25μF Capacitor

1

30

490106

415 Skin Pack
