2
INTRODUCTION
Safety Symbol Review and Signal Word Review
When you see these Safety Symbols and Signal Words on the
following pages, they will alert you to the possibility of serious
injury or death if you do not comply with the warnings that
accompany them. The hazard may come from something
mechanical or from electric shock. Read the warnings carefully.
When you see this Signal Word on the following pages, it will
alert you to the possibility of damage to your door
and/or the door operator if you do not comply with the cautionary
statements that accompany it. Read them carefully.
This door operator has been designed and tested to offer safe service provided it is installed, operated, maintained and tested in strict
accordance with the instructions and warnings contained in this manual.
Mechanical
Electrical
Introduction 2-4
Safety symbol review and signal word review . . . . . . . . . . . . . . . 2
Preparing your door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Carton inventory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Hardware inventory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Assembly 5
Attach the drive sprocket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Attach mounting brackets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation 6-12
Installation safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Install the door sprocket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Mount the operator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Attach the emergency release rope and handle . . . . . . . . . . . . . . 8
Install the single button control station . . . . . . . . . . . . . . . . . . . . 8
Electrical requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Install The Protector System
® . . . . . . . . . . . . . . . . . . . . . . . . 10-12
Adjustment 13-15
Program the travel limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Set the force . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Test The Protector System
® . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
To open door manually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Operation 16-18
Operation safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Using your operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Care of your operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Having a problem? (Troubleshooting) . . . . . . . . . . . . . . . . . . . . 17
Diagnostic chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Programming 19-20
To add or reprogram a hand-held
remote control (not provided) . . . . . . . . . . . . . . . . . . . . . . . . . . 19
To erase all codes from motor unit memory . . . . . . . . . . . . . . . 19
To add, program or change a keyless entry
PIN (not provided) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Repair Parts 21
Installation parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Motor unit assembly parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Accessories 22
Notes 23
Repair Parts and Service Back Page
TABLE OF CONTENTS
