Designing an MCN system
Page 30 MCN Comparator Display System Planner
9
a
b
Calculate the number of mounts required for Extended IIBs
(IIBs mounted near the CEB but not in the same rack as the comparator interfaces.):
Quad Single
Rack Mount Wall Mount
Extended IIBs ________ ________
Modules per Mount 4 1
Divide Extended IIBs by Modules per Mount and round up to the next whole number to calculate
Subtotal Mounts:
Subtotal Extended IIB Module Mounts________ ________
10
a
Calculate the number of mounts required for Extended HIBs (HIBs mounted near the PC and not
in the same rack as the comparator interfaces.)
Quad Single
Rack Mount Wall Mount
Extended HIB mounts ________** ________
** Normally, the PCs will be physically separated from each other and you will use one mount per
HIB module. You can rack HIBs together if they are all within 6 cable-feet of their PCs.
11
a
b
c
d
e
f
g
Total the number of mounts required based upon the subtotals in the last 3 steps:
DIGITAC Quad Single
Local Modules Rear Mount Rack Mount Wall Mount
Local Mounts (8g) ________ ________ ________
Ext. IIB Mounts (9b) N/A ________ ________
Ext. HIB Mounts (10a) N/A ________ ________
Totals Mounts ________ ________ ________
Enter the totals below and order the appropriate quantity of mounts:
S2-60437
DIGITAC Bracket and Cable Kit Qty: ________
S2-60435 Quad Rack Mount Kit Qty: ________
S2-60436 Wall Mount Kit Qty: ________
12
a
b
c
d
e
f
g
h
Parallel I/O Cabling (25-Pair Cables)
Enter the required number of cables for your system. See the Parallel I/O Cabling section for
more details.
Male to Male Male to Male Male to Blunt
CIB Modules 25’ Cable 10’ Cable 25’ Cable
DIGITAC Bracket/Cable **________ ________ N/A
DIGITAC Rack/Wall ________ ________ ________
Spectra-TAC, TAC, EGE ________ ________ ________
IIB Modules ________ ________ ________
Totals ________ ________ ________
** Order cables only if cables were not ordered with DIGITAC comparator.
Enter the totals below and order the appropriate quantity of items:
89-10837
Male to Male Cable 25’ Qty: ________
89-10711 Male to Male Cable 10’ Qty: ________
89-10843 Male to Blunt Cable 25’ Qty: ________
Continued
