Page 16 of 20 Rev: 1/21/2014 7:34 AM
Warranty Two years, limited
Operation
On-Levels 32 locally; increments of 1% with software
Ramp Rate
0.1 to 9 seconds if programmed locally; 0.125 seconds to 8
minutes if programmed with software
LED 1 dimmable white status LED
Operation Modes INSTEON only, X10 only, INSTEON and X10 combo
Combo Mode Message Order INSTEON, INSTEON cleanup, X10
Multi-Way Circuit Support
One ToggleLinc Dimmer controls load, Cross-Link any number
of ToggleLinc Dimmers or other INSTEON Controllers
Setup Memory Non-volatile EEPROM
INSTEON
INSTEON Address 1 hard-coded out of 16,777,216 possible
Maximum Scene Memberships 417
Scene Commands Supported as
Controller
On Fast-on
Off Fast-off
Dim Brighten
Scene Commands Supported as
Responder
On Fast-on
Off Fast-off
Dim Brighten
INSTEON Powerline Frequency 131.65KHz
INSTEON Minimum Receive Level 10mV
INSTEON Messages Repeated Yes
Mechanical
Paddle Type
Toggle
Wire Nuts
3 included
Mounting
Mounts in single or multiple-ganged junction box. Control 200W
less load for each immediately adjacent ToggleLinc Dimmer
installed. For example, 600 W load control becomes 400 W
with another dimmer to the immediate right or left. Use a triple-
gang box with a mechanical switch in the center to avoid de-
rating.
Wires
Line (black)
Load (red)
Neutral (white)
Ground (bare copper)
Dimensions 4.1" H x 1.8" W x 1.2" D
Weight 3.6 oz.
Operating Environment Indoors
Operating Temperature Range 32°F to 104°F
