2) Tap ToggleLinc’s Set button.
ToggleLinc status LED will double-blink.
You will have 4 minutes to complete the next step before multi-linking mode times out.
3) For each responder you are adding:
a. Tap on/off or press and hold to adjust responder to desired state.
b. Press and hold responder Set button until it beeps (or LED flashes).
ToggleLinc will double-beep.
4) After all responders have been added, tap ToggleLinc Set button.
ToggleLinc LED will stop blinking.
5) Test by tapping ToggleLinc on and off a couple of times.
All the responders added will respond.
Remove Multiple Scene Responders
1) Press and hold ToggleLinc’s Set button until it beeps.
ToggleLinc status LED will start blinking.
2) Press and hold ToggleLinc’s Set button until it beeps again.
ToggleLinc status LED will continue blinking.
3) Tap ToggleLinc’s Set button.
ToggleLinc status LED will double-blink.
You will have minutes to complete the next step before multi-unlinking mode times out.
4) For each responder you are removing:
a. If multi-button device, tap the responding button.
b. Press and hold responder Set button until it beeps (or LED flashes).
5) Tap ToggleLinc’s Set button.
ToggleLinc status LED will stop blinking.
6) Test by tapping controller button a couple of times
All responders removed will not respond.
Synchronizing Groups
Groups are scenes in which all members stay synchronized. Common examples include 3-way lighting
circuits and scenes with a single load-bearing device.
Example: 2-Switch Circuit
1) Link ToggleLinc Dimmer as a controller of another INSTEON device. (See Adding ToggleLinc
Dimmer as an INSTEON Controller.)
2) Link the same INSTEON device as a controller of ToggleLinc Dimmer. (See Adding ToggleLinc
Dimmer as an INSTEON Responder.)
3) Test the group by controlling the load from ToggleLinc Dimmer and the other device.
The load, ToggleLinc Dimmer’s LEDs and the other INSTEON device’s LEDs will remain in synch.
Example: Multi-Way Circuit
Although we recommend using home automation software (such as HouseLinc) to set up multi-way circuit
groups, the following steps will also work when carefully followed.
1) Turn on load(s) to desired same level.
2) Press and hold ToggleLinc Dimmer’s Set button until it beeps.
3) Tap ToggleLinc Dimmer’s Set button.
4) Initiate linking mode on secondary INSTEON device, usually by pressing and holding the Set button
for about 3 seconds.
5) Repeat step 3 for each addition INSTEON device in the circuit.
6) Once all INSTEON devices are in linking mode, tap ToggleLinc Dimmer’s Set button.
7) Repeat steps 2-6 for each device in the circuit until each has been linked as a controller and
responder of all group members.
8) Test the group by controlling the load(s) from ToggleLinc Dimmer and the other devices.
