Scan
Scan performs a frequency scan of the factory-defined and any
set-up user-programmable groups in order to find the group
with the highest number of clear receive channels. After about
20-30 seconds, the group with the highest number of clear re-
ceive channels will be displayed. The next best group and so
forth may be accessed with the [DOWN] and [UP] arow but-
tons.
•
Press and hold [MENU] + [SET] for three seconds to en-
ter Scan. The base station will now start searching all
groups for the ones with the greatest number of receiver
channels clear of interference.
•
Scan will display the group that has the most interference
free receive channels. These clear channels are displayed
on the right half of the screen. Press [SET] to place the
base station on this group and return to the operating
screen. The first four receive channels displayed will be
the ones set for the group. The [UP] / [DOWN] buttons
may be used to select the next best group and so forth.
6-9
Scan
Group 03A
OK?=[SET]
Next
01 05
02 06
03
04 08
Group 04b 01 05
OK?=[SET]
Prev
Next
06
03
04 08
[DOWN]
[SET]
Group 04b
4
R1
On
2
3
Tx
Tx
Tx
Tx
no tx
END
Scan
