2
The DX121 is a 2.4 GHz Wireless Intercom System. The Base Station will connect to a dynamic microphone
headset jack or a 4-Wire connector of a hardwired intercom station, and also provides battery-charging
capability for one battery. The system typically uses BP200 Beltpacs, but can also be used with the WH200
All-in-One Headset and/or WS200 Wireless Speaker Station COMMUNICATOR
®
s. Once connected to your
system, you can leave your console or intercom station while using a Communicator.
• Each Base Station supports one Communicator in full duplex, hands-free operation.
• Each Base Station supports up to four registered Communicators.
• Compatible with RTS and ClearCom/Production Intercom wired intercom headset or 4-Wire capable equipment.
NOTE: Use only with headset connectors capable of supporting dynamic microphone headsets.
• In the default mode, the ISO button activates relay-controlled contacts. For alternate operating mode, see
Relay Operation, page 22.
• The IC button activates audio to the 4-Wire and headset Input/Output connector(s).
• The ISO and IC buttons activate audio to other registered Communicators.
• The Base Station can charge a BAT41 battery in less than 3 hours.
• In case of power outage, the Base Station will operate temporarily from a battery in the charging port, for
approximately 30 minutes.
TYPICAL DX121 APPLICATIONS
Large Venue
SECTION 1. INTRODUCTION
