APPENDIX B - WIRING DIAGRAMS ST100 Series Flow Meter
46 Fluid Components International LLC
Figure B-17: Flow Element Connection - Remote
Figure B-18: Remote - 10 Conductor Interconnection Cable
RTD GND GND SEN REF SEN ACT SEN REF EXC ACT EXC HTR EXC #1 HTR RTN SIGN - SIGN +
1 2 3 4 5 6 7 8 9 10
C01062-1-1
HTR EXC #1 1
HTR RTN 3
ACT EXC 4
ACT SEN 5
GND SEN 6
GND 7
REF EXC 8
REF SEN 9
SHIELD 10
PRESS + 11
PRESS - 12
7
6 ACT EXC
5 REF EXC
4 ACT SEN
3 REF SEN
2 GND SEN
1 RTD GND
9 SIGN +
10 SIGN -
10 CONDUCTOR SHIELDED CABLE
LOCAL ENCLOSURE
TRANSMITTER
HTR EXC #1
8 HTR RTN
