CHAPTER 3 - OPERATION
Model MT91 Multipoint Flowmeter
3 - 4
Doc. No. 003185 Rev. B
Quick Custom Setup
In order to use the quick operation procedure, an assumption has been made that the password is enabled (this is the
factory preset condition).
If mistakes in data entry are made, press the back arrow key to correct mistake.
Menu level refers to the sequence of key to press to reach a particular function from the MAIN MENU. For
example, to go to menu level 2.2.1, press HOME, 2, 2, and 1.
Y/N refers to Y Save Permanently or Change Parameter or N Do Not Save Permanently or Do Not Change
Parameter.
Using Main Functions
MAIN MENU
Press HOME.
Returns user to MAIN MENU. In some cases, it may be necessary to press
HOME more than once.
NORMAL DISPLAY
menu level 1.
To view the NORMAL DISPLAY
DelR and RefR
menu level 4.2.5
To view a sensing point's raw signal DelR and RefR. When prompted, enter
the number of the sensing point to be viewed.
PASSWORD
menu level 2.5.1.2
Enable or Disable the PASSWORD
PASSWORD
menu level 2.5.1.1
Change the user PASSWORD. If the password protection is enabled, the
user must enter the current password.
Selecting Units of Measurement
After reaching the menu level, select the combination of units that will produce the desired end result.
Velocity units
menu level 2.1.1.1
Length
1=FT, 2=M and
Time
1=Sec, 2=Min, 3=Hrs, 4=Day
Volume units
menu level 2.1.1.2
Volume
1=SCF, 2=NCM, 3=NLP
Area
1=Square Feet, 2=Square Meters
Area Value
enter the area of the duct
Time
1=Sec, 2=Min, 3=Hrs, 4=Day
Mass units
menu level 2.1.1.3
Mass
1=LBM, 2=KG, 3=TON, 4=TONNE
Area
1=Square Feet, 2=Square Meters
Area Value
enter the area of the duct
Time
1=Sec, 2=Min, 3=Hrs, 4=Day
Temperature units
menu level 2.1.2
1=°F 2=°C 3=K 4=°R
