TECHNICAL SPECIFICATIONS
FLT
®
Series FlexSwitch
TM
8
Fluid Components International LLC
Application
Flow rate and /or level /interface and temperature sensing in liquid,
gas and slurry applications.
Sensing Elements
Process Connection
Models S and F
3/4 inch male NPT standard; optional 1 inch BSP, 1 inch male
NPT, 3/4 inch Male NPT (FLT93-F only); fl anges, or spool pieces.
Model L
1” male NPT or 3/4” female NPT, both ends with orifi ce;
fl anges optional.
Insertion Length
Models S and F
Available in standard lengths of 1.2” [30mm], 2” [51mm],
4” [102mm], 6” [152mm], 9” [229mm], 12” [305mm],
18” [457mm] and custom-specifi ed lengths.
Model L
3.375” [86mm] in-line body length
Sensing Element
Models S and F
All wetted surfaces are 316L stainless steel with all-welded
construction. Hastelloy C, Monel 400, electro-polished
stainless steel and titanium (FLT93-S only) are optionally
available.
Model L
All wetted surfaces are 316L stainless steel with all-welded
construction. Hastelloy C, Monel 400 and titanium are
optionally available.
Operating Temperature
Sensing Element:
All Models
Standard temperature confi guration:
-40°F to +350°F [-40°C to +177°C]
Medium temperature confi guration:
-100°F to +500°F [-73°C to +260°C]
Model S Only
High temperature confi guration:
-100°F to +850°F [-73°C to +454°C]
Control Circuit:
All Models
Ambient -40°F to +140°F [-40°C to + 60°C]
Operating Pressure
Models S, F and L
2350 psig [ 162 bar(g)] maximum at 500°F [260°C]
1450 psig [100 bar(g)] maximum at 850°F [454°C]
Control Circuit Features
Control Circuit
Standard: Plug-in, socket mounted with dual alarm/trip epoxy sealed
relays.
Optional: Rack-mount confi guration (card cage or enclosure not
included)
Output Signal
Analog DC voltage related to fl ow or level / interface signal and
proportional to temperature, standard.
Input Power
Field selected or pre-confi gured in the factory to 115 Vac (±15),
230 Vac (±30, 50 to 60 Hz), 24 Vdc (+4, -3) or 24 Vac (+2, -6);
100 Vac ±10 optionally available. LED indicates power on.
Power Consumption
AC units, 13 VA maximum; DC units, 7 watts maximum.
Heater Power
Field or factory selected to optimize switching performance and
rangeability and selectable for specifi c fl uid service requirements.
7 watts power consumption, 230 mA maximum.
Typical Service
Sensing Element
Power (W)
Gas or Air
S-Style
0.75
F-Style
0.25
Liquids
S-Style
3.0
The above typical service power selections are for reference
only. Depending on application requirements, surface temperature
rating requirements, and rangeability expectations, alternate power
selections may be recommended. Other intermediate power selec-
tions can be made. Consult installation manual for recommendations
in your service.
Relay Rating
Dual SPDT or single DPDT fi eld confi gurable 6 amp resistive at 115
Vac, 240 Vac or 24 Vdc; hermetically sealed relay confi gurations
optionally available.
Electrical Enclosure
Aluminum (epoxy coated) or optional stainless steel. Enclosures are
rated for hazardous location use (Class I and II, Division 1 and 2,
Group B, C, D, E, F and G; and EEx d IIC) and resists the effect of
weather and corrosion (NEMA and CSA Type 4X and equivalent to
IP66).
For Flow Service
Setpoint Range
Model S
Water-based Liquids:
0.01 FPS to 0.5 FPS [0.003 MPS to 1.52 MPS]with 0.75 watt heater;
0.01 FPS to 3.0 FPS [0.003 MPS to 0.9 MPS] with 3.0 watt heater.
Hydrocarbon-based Liquids:
0.01 FPS to 1.0 FPS [0.003 MPS to 0.3 MPS] with 0.75 watt heater;
0.01 FPS to 5.0 FPS with [0.003 MPS to 1.5 MPS] with 3.0 watt
heater.
Air/Gas:
0.25 SFPS to 120 SFPS [0.08 NMPS to 37 NMPS] with 0.75 watt
heater at standard conditions; 70°F [21.1°C], 14.7 psia [1.013
bar(g)].
Other Fluids: Contact the factory for approximate rangeability.
Model F
Air/Gas:
0.25 SFPS to 120 SFPS [0.08 NMPS to 37 NMPS] 0.75 watt heater
at standard conditions; 70°F [21.1°C], 14.7 psig [1.013 bar(g)].
Model L
Water-based Liquids: 0.015 cc/sec to 50 cc/sec
Hydrocarbon-based Liquids: 0.033 cc/sec to 110 cc/sec
Air/Gas: 0.6 cc/sec to 20,000 cc/sec
