Technical Data
6.6. General Technical Data
6.6.1. Mechanical data
Dimensions: See chapter “6.6.2. Dimensions”
Weight: 25 – 75 Nm; 4 kg
100 – 300 Nm; 6.5 kg
Housing material: Cover and housing made of epoxy-coated aluminium
Axles and screws made of stainless steel
Gears made of galvanized steel
Actuating angle: 90° (optional 180°, 270°) ± 5°
Duty cycle: 50% at maximum torque (optionally 80%)
Manual emergency actuation: with open-end wrench on faces of the axle (up to 75 Nm);
by handwheel (from 100 Nm)
Working modes: Open/Closed mode or Three points mode
(see figure “Figure 16” and “Figure 17”)
