TECHNICAL CHARACTERISTICS
OPERATING TEMPERATURE
CONVERTER
Ambient Temp.
Min. Max
°C °F °C °F
-20* -4* 60 140
ELECTRIC CHARACTERISTICS
Classification of the instrument: class I, IP 67, category of installation II
Power supply
versions
Power supply
voltage
Power supply
frequency
Pmax
current
max
HV 90÷265 Vac 44÷66 Hz 20W/25VA 0,25 A
LV 18÷45 Vac/dc 0-44÷66 Hz 20W/25VA 1,6 A
LLV 10÷35 Vdc 20 W 1,5 A
INPUT/OUTPUT ISOLATION
Input/output are insulated up to 500V
q
The output 4÷20 mA and the output 24 Vdc are electrically connected
ENVIRONMENTAL CONDITIONS OF USE
The instrument can be installed inside or outside buildings
Altitude: from –200 a 6000 m (from -656 to 19685 feet)
Humidity range: 0÷100% (IP 67)
q
Line voltage range: (see table on technical characteristics)
* For discontinuous use, the installation of a heating resistance is necessary
