Fixing screw
of board
q Unscrew the screws suitable in pic. 1
Lift the board, take off the flat cable
from the display pic. 2 and extract
definitely the board from the box
Pic.2
4 allen spanner Display
Unscrew the fixing screw of display to
allow the shift of the angular and the
extraction of the display
N.B.: don't unscrew entirely the screw
Take off the
flat cable
1
2
3 4
Display
q Rotate the display in the desired location,
verify the correct set of the seal, the
cleaning of the contact surfaces of and set
the display in the lodging.
q Shift the angular in the suitable direction
(pic. 5) and screw down the scew, till to
the support perception of the angular on
the display
q Shut definitely the screw in the order
1-2-3-4 suitable in represents pic. 4
Pic.6
Pic.4
Pic.7
APPENDIX 1
Display rotation
Pic.1
Pic.3
Restore the connection of the flat cable to
the display
Verify the correct set of the board in the
fixing clip ( Pic.7 )
Finish the assemblage fixing to the box
the board
Pic.5
