FACTORY PRE-SETTINGS
ACCESS CODES
The converter is delivered with access code L2:
11111
and with the "Quick start menu" enable. Press
the key to access to the "Quick start menu"
from one of the visualization pages
The “Quick start menu” it’s enable by 8.6 function
(display menu); from the “Quick start menu” the
functions may be set without entering any access
code (see example 1 on page 24).
The last function allows to access the main menu.
the block level enables or disables the access to
the functions of the converter.
The available levels of block are the following:
(Menu “11 Internal data” pos. 11.2)
q Level 0: it completely disables the access to
the functions. You can perform the following
functions through the keyboard:
§ Changing the display mode
§ Dosing Start/stop
§ Data printing
q Level 1: it enables the access to the
following functions:
• Totalise re-setting
• Dosing functions modifications
q Level 2: it enables the access to the
following functions:
§ Quick start menu
§ Scale (full enabling)
§ Display (partial enabling)
§ Diagnostics (partial enabling)
q Level 3: it enables the access to all the
functions of level 2
ACCESS CODES
Some functions in the converter are enabled by the
access codes. The information’s of this manual are
related to all the functions available with L2 level.
All the functions available through higher level are
protected and reserved to the service.
Description of the L2 access code
(Menu “11 Internal data” pos. 11.1)
q with code L2 = 00000 you disable the
request of code
NOTE: the availability of the functions is
related to the selected block
q * with L2 customised (freely chosen by the
user) you can proceed programming all the
functions up to L2 security level, entering the
code itself whenever you need enter the Main
menu
*ATTENTION: take note very carefully of the
customised code you have chosen, since there is
no way for the user to retrieve it if it forgotten
BLOCK LEVELS
FACTORY PRE-SETTINGS
BLOCK LEVELS
The converter is delivered with the following
block level:
3
If for several reasons you need to change the
block level, follow the steps:
q Set the dip switch on OFF position
q Access to the function “
Block level ” of menu
11 (main menu)
q Choose the desired level of block
To enable the selected block level place the DIP
switch on the ON position
When the Dip-switches are on “OFF”, all
functions are available.
LOCK
Dip
switch
(ON) (OFF)
